Recycling Equipment for Baled Scrap

Sorting machinery is critical. The magnetic separator uses the principle of electromagnetic induction to build a strong magnetic field inside the device. When the mixed waste passes through the conveyor belt of the magnetic separator, the ferromagnetic material (such as scrap steel, etc.) is attracted by the magnetic field, deviates from the original conveying track, and is adsorbed to the collection area of the magnetic separator to achieve the initial separation from other waste. The optical sorter has a high-resolution camera and a complex image recognition algorithm. The camera quickly scans the waste on the conveyor belt to obtain multidimensional information such as color, texture, and material reflectivity, and transmits the data to the central processor. After the algorithm analysis, it can accurately identify different kinds of materials, such as plastic, metal, glass, etc., and then control the high-pressure jet device, jet air to the target waste, blow it away from the main conveyor belt, complete accurate classification, and effectively improve the purity of recovery.

In the crushing equipment, the hammer mill shredder has a fixed jaw plate and a movable jaw plate, both in a V-shaped layout. When large pieces of waste enter the crushing chamber, the motor drives the eccentric shaft to rotate, so that the movable jaw plate does reciprocating movement, the waste is squeezed and split, and its size is reduced. A high-speed rotating rotor is installed inside the hammer mill shredder, and a plurality of hammer heads are fixed on the rotor. After the coarse crushed waste enters the crushing chamber, it is violently impacted and thrown by the high-speed rotating hammer head, and further refined by collision with the crushing chamber wall to meet the requirements of subsequent recycling and utilization of the material particle size.
